WGH Series


The MF-WGH Series is the most novel fuel cell power module that is designed for different continuous power generation application using hydrogen as the energy source. MF-WGH Series can be integrated for transportation, stationary, decentralized generator applications. The advantage of the liquid-cooling platform of WGH series includes higher stack efficiency, useful heat recovery, and higher stack power density with expected stack lifetime up to 2,0000 hours. The MF-WGH Series comes with 4, 6, 8, and 10kW power modules and can be integrated in parallel or series to build to your desired fuel cell system.
The MF-WGH Series is aimed to extend the product line of the previous the MF-LPH Series, to provide full fuel cell module portfolio from 1kW to 10kW as the building block for all kinds of fuel cell solution scenario.

MF-WGH Series
Module Specifications
Product Description Fuel Cell Power Module Power Output 6kW/8kW/10kW
Input Voltage 24V/48V Output Voltage 45~75V/57~95V/72.5~120V
Maximum Current Output 135A Fuel Spec Hydrogen (Purity: >99.95%)
Fuel Pressure 44~120 psi (3~8.2 bar) Dimensions Varies
Weight 40/50/60 kg Cooling System Water
Operating Efficiency
Hydrogen Consumption 752 Liter / kW-hr Fuel Cell Efficiency >50%
Environmental Condition
Ambient Temperature 0~50°C Location Indoor/Outdoor
Specifications and descriptions in this document were in effect at the time of publication. M-FIELD ENERGY LTD.
reserves the right to change specifications, product appearance or to discontinue products at any time, Copyright © 2019 M-FIELD ENERGY LTD.
